The most widely used interface in factory automation. Our M8/M12 range covers every coding for sensors, fieldbus and high-speed Ethernet, fully compatible with industry standard pinouts (IEC 61076-2-101 / -2-109). All products are high-quality compatible alternatives – drop-in replacement at a competitive price.
M12 X-Coded (10GbE)
8-pole, 10 Gigabit Ethernet (Cat 6A). Ideal for machine vision, backbones and high-bandwidth IIoT.
| Coding | X |
| Poles | 8 |
| Data rate | 10 Gbps |
| Bandwidth | 500 MHz |
| Voltage/Current | 48V / 0.5A |
| IP rating | IP67 |
| Standard | IEC 61076-2-109 |
| Cable OD | 6-8 mm |
M12 D-Coded (Ethernet)
4-pole, 100 Mbps Ethernet / PROFINET. Shielded versions for EMC-critical environments.
| Coding | D |
| Poles | 4 |
| Data rate | 100 Mbps |
| Bandwidth | 100 MHz |
| Voltage/Current | 250V / 4A |
| IP rating | IP67 |
| Standard | IEC 61076-2-101 |
| Cable OD | 6-8 mm |
M12 A-Coded (Sensors)
3/4/5/8/12-pole for sensors, actuators and IO. IP67, gold-plated contacts.
| Coding | A |
| Poles | 3/4/5/8/12 |
| Voltage/Current | 63V/4A (250V variants) |
| IP rating | IP67 |
| Termination | Screw / crimp |
| Contacts | Gold-plated |
| Standard | IEC 61076-2-101 |
| Cable OD | 6-8 mm |
M8 Circular (Mini)
3/4-pole miniature connectors for compact sensors and actuators in tight spaces.
| Size | M8 |
| Poles | 3/4 |
| Voltage/Current | 60V / 3A (30V / 4A) |
| IP rating | IP67 |
| Standard | IEC 61076-2-104 |
| Cable OD | 3.5-5 mm |
| Termination | Solder / screw |
TE SPE-M12 Hybrid
Single Pair Ethernet + power in one M12 housing – one cable for data and power.
| Type | SPE + Power hybrid |
| Data | 1 Gbps over single pair |
| Power | 16A @ 63V DC |
| IP rating | IP67 |
| Standard | IEC 61076-2-111 |
| Coding | SPE (IEC 63171-5 compatible) |
| Cable OD | 6-8 mm |
Specifications are typical values. Please contact us for the latest datasheets and custom cable assemblies.
